SectionLift Product Range
We offer an extensive range of equipment for sale from 3 tonnes to 3000. The list below shows our hire capability. Other weights and spans are achievable, please contact our technical team for details. All our systems are available for national delivery.
SectionLift 6
- Minimum Beam Length: 500mm
- Maximum Beam Length: 4 metres
- Max. Load Capacity: 8 tonnes at 2 metres
- 6 tonnes capacity at 3 metres span
SectionLift 10
- Minimum Beam Length: 500mm
- Maximum Beam Length: 10 metres
- Max. Load Capacity: 16 tonnes at 5.5 metres
- 10 tonnes capacity at 7 metres span
SectionLift 20
- Minimum Beam Length: 500mm
- Maximum Beam Length: 12 metres
- Max. Load Capacity: 24 tonnes at 5.5 metres
- 20 tonnes capacity at 6 metres span
SectionLift 50
- Minimum Beam Length: 1000mm
- Maximum Beam Length: 16 metres
- Max. Load Capacity: 50 tonnes at 6 metres
- 40 tonnes capacity at 8 metres span
SectionLift 80
- Minimum Beam Length: 1000mm
- Maximum Beam Length: 20 metres
- Max. Load Capacity: 80 tonnes at 11 metres
- 50 tonnes capacity at 15 metres span
SectionLift 110
- Minimum Beam Length: 1000mm
- Maximum Beam Length: 22 metres
- Max. Load Capacity: 170 tonnes at 8.5 metres
- 110 tonnes capacity at 12 metres span
SectionLift 250
- Minimum Beam Length: 1500mm
- Maximum Beam Length: 32 metres
- Max. Load Capacity: 300 tonnes at 8.5 metres
- 250 tonnes capacity at 10 metres span
SectionLift 500
- Minimum Beam Length: 1500mm
- Maximum Beam Length: 32 metres
- Max. Load Capacity: 650 tonnes at 8 metres
- 150 tonnes capacity at 32 metres span
Selection of SectionLift Hire Equipment
